RUD VLBG-PLUS-8t-M36 Load Ring with RUD-bolt
- Optimum WLL with captive but exchangable ICE-Bolt
- Bracket adjustable in force direction
- Comprehensive range of threads
- DNV certification from size M30.
Specification
Name
RUD VLBG-PLUS-8t-M36 Load Ring with RUD-bolt
SKU
VLBG-PLUS-8t-M36
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 5.97 kg | 13.23 lbs |
| Nominal WLL | 8000 kg | 17630 lbs |
| T | 196 mm | 7-3/4" |
| A | 77 mm | 3"-1/32" |
| B | 122 mm | 4-13/16" |
| C | 82 mm | 3-1/4" |
| D | 70 mm | 2-3/4" |
| E | 97 mm | 3-13/16" |
| F | 26.5 mm | 1-3/64" |
| G | 77 mm | 3"-1/32" |
| H | 63 mm | 2-15/32" |
| I | 205 mm | 8-1/16" |
| K | 113 mm | 4-11/32" |
| L | 140 mm | 5-1/2" |
| M | M36 mm | M36 |
| N | 79 mm | 3-7/16" |
