RUD VLBG-PLUS-3.5t-M20 Load Ring with ICE-bolt
- Optimum WLL with captive but exchangable ICE-Bolt
- Bracket adjustable in force direction
- Comprehensive range of threads
- DNV certification from size M30.
Specification
Name
RUD VLBG-PLUS-3.5t-M20 Load Ring with ICE-bolt
SKU
VLBG-PLUS-3.5t-M20
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 1.30 kg | 2.87 lbs |
| Nominal WLL | 3500 kg | 7700 lbs |
| T | 110 mm | 4-11/32" |
| A | 50 mm | 1-31/32" |
| B | 82 mm | 3-1/4" |
| C | 54 mm | 2-1/8" |
| D | 45 mm | 1-25/32" |
| E | 55 mm | 2-5/32" |
| F | 17 mm | 43/64" |
| G | 43 mm | 1-11/16" |
| H | 32 mm | 1-1/4" |
| I | 113 mm | 4-7/16" |
| K | 64 mm | 2-1/2" |
| L | 75 mm | 2-15/16" |
| M | M20 mm | M20 |
| N | 48 mm | 1-7/8" |
