RUD VLBG-PLUS-6.7t-M30 Load Ring with RUD-bolt
- Optimum WLL with captive but exchangable ICE-Bolt
- Bracket adjustable in force direction
- Comprehensive range of threads
- DNV certification from size M30.
Specification
Name
RUD VLBG-PLUS-6.7t-M30 Load Ring with RUD-bolt
SKU
VLBG-PLUS-6.7t-M30
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 3.22 kg | 7.10 lbs |
| Nominal WLL | 6700 kg | 14770 lbs |
| T | 147 mm | 5-25/32" |
| A | 60 mm | 2-3/8" |
| B | 103 mm | 4-1/16" |
| C | 65 mm | 2-9/16" |
| D | 60 mm | 2-3/8" |
| E | 67 mm | 2-5/8" |
| F | 22.5 mm | 7/8" |
| G | 61 mm | 2-13/32" |
| H | 49 mm | 1-15/16" |
| I | 151 mm | 5-15/16" |
| K | 80 mm | 3-1/8" |
| L | 110 mm | 4-11/32" |
| M | M30 mm | M30 |
| N | 67 mm | 2-5/8" |
