RUD VRS-20t-M64 Vario Eye Bolt Starpoint
- 360° adjustable in force direction
- several times higher WLL than the DIN 580 eye bolt
- Easy-Fit-Key for easy assembly and disassembly available, look type VRS-F
Specification
Name
RUD VRS-20t-M64 Vario Eye Bolt Starpoint
SKU
VRS-20t-M64
Brand
Condition
New
| Attribute | Value | Value |
|---|---|---|
| weight | 16.41 kg | 36.18 lbs |
| Nominal WLL | 20000 kg | 44090 lbs |
| T | 177 mm | 6-31/32" |
| B | 55 mm | 2-5/32" |
| C | 49 mm | 1-15/16" |
| D | 120 mm | 4-3/4" |
| E | 121 mm | 4-3/4" |
| G | 158 mm | 6-1/4" |
| I | 90 mm | 3-17/32" |
| K | 229 mm | 9" |
| L | 96 mm | 3-25/32" |
| M | M64 mm | M64 |
| N | 36 mm | 1-27/64" |
