RUD VRS-16t-M56 Vario Eye Bolt Starpoint
- 360° adjustable in force direction
- several times higher WLL than the DIN 580 eye bolt
- Easy-Fit-Key for easy assembly and disassembly available, look type VRS-F
Specification
Name
RUD VRS-16t-M56 Vario Eye Bolt Starpoint
SKU
VRS-16t-M56
Brand
Condition
New
| Attribute | Value | Value |
|---|---|---|
| weight | 11.99 kg | 26.43 lbs |
| Nominal WLL | 16000 kg | 35270 lbs |
| T | 161 mm | 6-11/32" |
| B | 50 mm | 1-31/32" |
| C | 44 mm | 1-3/4" |
| D | 110 mm | 4-11/32" |
| E | 112 mm | 4-13/32" |
| G | 145 mm | 5-11/16" |
| I | 82 mm | 3-1/4" |
| K | 210 mm | 8-1/4" |
| L | 84 mm | 3-5/16" |
| M | M56 mm | M56 |
| N | 32 mm | 1-1/4" |
