RUD VRS-9t-M42 Vario Eye Bolt Starpoint
- 360° adjustable in force direction
- several times higher WLL than the DIN 580 eye bolt
- Easy-Fit-Key for easy assembly and disassembly available, look type VRS-F
Specification
Name
RUD VRS-9t-M42 Vario Eye Bolt Starpoint
SKU
VRS-9t-M42
Brand
Condition
New
| Attribute | Value | Value |
|---|---|---|
| weight | 4.60 kg | 10.14 lbs |
| Nominal WLL | 9000 kg | 19840 lbs |
| T | 121 mm | 4-3/4" |
| B | 37 mm | 1-7/16" |
| C | 33 mm | 1-5/16" |
| D | 84 mm | 3-5/16" |
| E | 86 mm | 3-3/8" |
| G | 111 mm | 4-13/32" |
| I | 62 mm | 2-7/16" |
| K | 158 mm | 6-1/4" |
| L | 63 mm | 2-15/32" |
| M | M42 mm | M42 |
| N | 24 mm | 15/16" |
