WEICON Plastic Metal WR Steel Filled Liquid Epoxy Resin System for Casting and Gap Compensation
WEICON WR is suitable for areas where metal parts are exposed to strong wear due to friction. For example, the epoxy resin system can be used for repairs and recasting of shafts, for pouring out bearings as well as cutting and punching tools, for the production of casting and profile milling models as well as drawing moulds, for the underpouring of machines and foundations and as wear-resistant base layer before the final coating with WEICON Ceramic BL. It can be used in mechanical engineering, toolmaking, model and mould making as well as many other areas.
Specification
Name
WEICON Plastic Metal WR Steel Filled Liquid Epoxy Resin System for Casting and Gap Compensation
Brand
Condition
New
| WEICON SPESIFICATION | |
| Base | Epoxy |
| Filler | Steel |
| Texture | Liquid |
| Colour | Black |
| Processing Temperature | +15°C to +40°C |
| Component Temperature | >3 °C above dew point |
| Relative Air Humidity | < 85% |
| Mixing Ratio by Weight | 100:15 |
| Mixing Ratio by Volume | 100:43 |
| Viscosity of the Mixture at +25°C | 4000-5000 mPa·s |
| Density of the Mixture | 2.4 g/cm³ |
| Consumption (Layer Thickness 1.0 mm) | 2.4 kg/m² |
| Max. Layer Thickness per Step | 10 mm |
