WEICON Copper Paste is a protection, release and lubricating agent and is resistant to high temperatures and corrosion. It provides strong adhesion and contains no sulphur, lead or nickel. Copper Paste is used as an assembly lubricant for all kinds of threaded joints and sliding surfaces. It forms an effective lubricating and separating film, which protects the functional surfaces on plug-in tools, wear bushings, screws, and all kinds of threaded, plug-in and bayonet joints against corrosion and seizing. It can be used to reduce vibration on brake blocks and guides, brake cams and pins, car and truck battery terminals and other electrical connections, wheel bolts and nuts, and on wear bushings at electrical, compressed air and hydraulic hammers.
| Consistency classification | DIN 51818, NLGI grade 1 |
| Base | Mineral Oil |
| Dry lubricant | Copper ground/graphite |
| Colour | Copper |
| Density | (+20°C) DIN 51757, 1.1 g/cm³ |
| Silicone-free | Yes |
| Four ball weld test property load | DIN 51350, 0 N |
| Four ball weld test weld load | DIN 51350, 3,200 N |
| Four ball weld test calotte value | DIN 51350 (1min/1000N), 0 mm |
| Cone penetration | DIN ISO 2137, 310 - 340 1/10 mm |
| Heat capacity | DIN EN ISO 22007-4, 1,713 J/(g·K) |
| Thermal conductivity | 0.392 W/m·K |
| Dielectric strength | DIN EN 60243-1 (20°C), 1.7 kV/mm |
| Dripping point | IP 396, +180 °C |
| Kinematic viscosity (40 °C) | DIN 51 562, 180 mm²/s |
| Temperature conductivity | 0.208 mm²/s |
| Temperature resistance | -20 °C to 1,100 °C |
| Shelf life | 24 months |
| Thickener | Alu-complex soap |
