RUD VLBG-PLUS-20t-M48 Load Ring with RUD-bolt
- Optimum WLL with captive but exchangable ICE-Bolt
- Bracket adjustable in force direction
- Comprehensive range of threads
- DNV certification from size M30.
Specification
Name
RUD VLBG-PLUS-20t-M48 Load Ring with RUD-bolt
SKU
VLBG-PLUS-20t-M48
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 11.60 kg | 25.57 lbs |
| Nominal WLL | 20000 kg | 44090 lbs |
| T | 222 mm | 8-3/4" |
| A | 95 mm | 3-3/4" |
| B | 156 mm | 6-5/32" |
| C | 100 mm | 3-15/16" |
| D | 95 mm | 3-3/4" |
| E | 105 mm | 4-1/8" |
| F | 36 mm | 1-27/64" |
| G | 87 mm | 3-7/16" |
| H | 73 mm | 2-7/8" |
| I | 230 mm | 9-1/16" |
| K | 130 mm | 5-1/8" |
| L | 160 mm | 6-13/32" |
| M | M48 mm | M48 |
| N | 100 mm | 3-15/16" |
