Hydraulic and Pneumatic Sealant WEICONLOCK AN 305-42 LOCTITE 545
Specification
Name
Hydraulic and Pneumatic Sealant WEICONLOCK AN 305-42 LOCTITE 545
SKU
AN 305-42
Brand
Condition
New
| WEICON SPESIFICATION | ||
| Colour | brown | |
| Fluorescent | yes | |
| For thread connections up to | M 20 R ¾" | |
| Viscosity | 500 nt mPa·s | |
| Gap bridging up to max. | 0,15 mm | |
| Breakaway torque | 12 - 15 Nm | |
| Prevail torque | 18 - 22 Nm | |
| Shear strength Nmm² (DIN 54452) | 8 - 12 N/mm² | |
| Handling strength | 10 - 20 min | |
| Final strength | (100 % strength) | 2-4 h |
| Temperature resistance | -60 to +150 degree C | |
| Compressive strength (free cutting steel / grub screw = 8.8) | ||
| M_3x6 | max. | 1500 bar |
| M_4x6 | max. | 1500 bar |
| M_5x8 | max. | 1500 bar |
| M_6x10 | max. | 1200 bar |
| M_8x12 | max. | 800 bar |
| M_10x16 | max. | 700 bar |
| LOCTITE SPESIFICATION | |
| Application | Hydraulic/Pneumatic Sealing, Pipe Sealing, Thread Sealing |
| Physical Form | Liquid |
| Key Characteristics | Lubricity: High Lubricity, Solvent Resistant, No Fillers/Particles, Viscosity: Medium Viscosity |
| Application Method | Manual, Dosing system |
| Substrate | Thread Type: Smooth, Metal |
| Operating Temperature | -55.0 - 150.0 degree C (-65.0 - 300.0 degree F ) |
| Technology | Acrylic |
| Drying Type | Anaerobic Drying |
| Movement Torque, Steel M10 | 2.0 N·m (20.0 in/lb. ) |
| Viscosity, 20 RPM | 15000.0 mPa.s (cP) |
| Color | Purple |
