WEICON 10000047 Zinc Spray Bright Grade (400ML)
WEICON Silicone N is free of solvents, neutrally vulcanizing, strong, permanently elastic, resistant to weathering, ageing and chemicals, temperature-resistant up to +180 °C (+356 °F), extremely elastic (breaking elongation of approx. 550%) and can be used universally. Silicone N adheres very well to all metals, glass, ceramics, and many other materials. Silicone N can be used in plastic processing, the electrical industry, energy technology, the lighting industry, exhibition construction and shopfitting, and in many other industrial areas.
Specification
Name
WEICON 10000047 Zinc Spray Bright Grade (400ML)
SKU
4024596000387
Brand
Condition
New
| Material Properties – 1-C. Polysiloxane (Oxime) | |
|---|---|
| General Properties | |
| Base | 1-C. polysiloxane (oxime) |
| Colour | Transparent |
| Cure type | Moisture-curing |
| Stability/run-off (ASTM D 2202) | 1.0 mm |
| Density | 1.01 g/cm³ |
| Curing conditions | +5°C to +40°C, 30–95% rel. humidity |
| Processing temperature | +5°C to +35°C |
| Curing speed (first 24h) | 2–3 mm |
| Skin-over time | 7 min |
| Gap bridging | Up to 5 mm |
| Max. sealing joint width | 25 mm |
| Mechanical Properties | |
| Tensile strength (ISO 37 / S3A) | 1.5 N/mm² |
| Tensile strength (pure adhesive/sealant, ISO 37) | 1.5 N/mm² |
| Elongation at break (ISO 37 / S3A) | 550 % |
| Elongation at 100 % (ISO 37 / S3A) | 0.4 N/mm² |
| Movement absorption | Max. 25 % |
| Volume change (DIN 52451) | <-6 % |
| Hardness (Shore A, DIN ISO 7619) | 20±5 |
| Thermal Properties | |
| Temperature resistance | -50°C to +180°C |
| Electrical Properties | |
| Resistance | 1·10¹² Ω·m |
| Dielectric strength | 17.0 kV/mm |
| Classification | |
| Building material class (DIN 4102) | B 2 |
| Shelf life | 12 months |
