WEICON Black-Seal is black, high-temperature-resistant (+280 °C/+536 °F), free of solvents, strong, oil-resistant, grease-resistant, pressure-resistant, resistant to ageing and extremely elastic (breaking elongation of approx. 500%). It is suitable for bonding and sealing in applications where particularly high oil and grease resistance is required. The product can be used on gearbox, valve and casing covers, oil sumps, water pumps, gears and axles, flanges, tanks and containers, and in many other areas.
LOCTITE® SI 5690 is a non-corrosive, oil-resistant, moisture-curing gasketing sealant, ideal for copper and applications involving large gaps. It can also be used for electrical insulating applications and is compatible with various surfaces, including metals and plastics. LOCTITE® SI 5690 cures when exposed to moisture in the air to form a rigid rubber gasket. Its thixotropic nature makes it easy to apply and reduces sealant migration after application. LOCTITE® SI 5690 is label-free and offers excellent adhesive strength, even at temperatures up to 350°C (662°F).
- Thixotropic for ease of application
- Moisture-curing
- Room temperature vulcanizing (RTV) curing
- Non-corrosive
- Temperature resistant up to 350°C (662°F)
| WEICON SPESIFICATION | |
| Base | 1-C. polysiloxane (acetate) |
| Colour | Black |
| Solid Content | 96% |
| Cure Type | Moisture-curing |
| Stability/Run-off (ASTM D 2202) | 1.0 mm |
| Density | 1.06 g/cm³ |
| Curing Condition | +5°C to +40°C and 30% to 95% rel. air humidity |
| Processing Temperature | +5°C to +35°C |
| Curing Speed in the First 24 h | 2 - 3 mm |
| Skin-over Time | 7 min. |
| Gap Bridging (up to max.) | 5 mm |
| Max. Sealing Joint Width | 25 mm |
| Tensile Strength (ISO 37 / S3A) | 2 N/mm² |
| Tensile Strength of the Pure Adhesive and Sealant (ISO 37) | 2 N/mm² |
| Elongation at Break (Tensile) (DIN 53504/ASTM D412) | 500% |
| Medium Lap Shear Strength (DIN EN 1465/ASTM D 1002) | 0.7 N/mm² |
| Elongation at Break (ISO 37, S3A) | 470% |
| Tear Resistance (DIN 53515 / ASTM D 1002) | 4 kN/m |
| Elongation at 100% (ISO 37 S3A) | 0.7 N/mm² |
| Movement Absorption (max.) | 15% |
| Volume Change (DIN 52451) | -9% |
| Hardness (Shore A) (DIN ISO 7619) | 30±5 |
| Temperature Resistance | -60°C to briefly +280°C (approx. 2 h), +300°C |
| Thermal Conductivity | 0.2 W/m·K |
| Resistance | 2.5 x 10^15 Omega x m |
| Dielectric Strength | 21.0 kV/mm |
| Building Material Class (DIN 4102) | B 2 |
| Shelf Life | 12 months |
| LOCTITE SPESIFICATION | |
| Color | Copper |
| Cure speed vs time, 24.0 hr. | 2.5 mm |
| Gap fill | 1.0 mm |
| Lab shear strength | 1.03 N/mm² |
| Recommended for use with | Metal, Plastic |
