Flange Sealing WEICONLOCK AN 305-18 LOCTITE 515
Specification
Name
Flange Sealing WEICONLOCK AN 305-18 LOCTITE 515
SKU
AN 305-18
Brand
Condition
New
| WEICON SPESIFICATION | ||
| Colour | Red | |
| Fluorescent | Yes | |
| Viscosity | 80,000 - 500,000 ht mPa·s | |
| Gap Bridging up to max. | 0.5 mm | |
| Breakaway Torque | 12 - 18 Nm | |
| Prevail Torque | 18 - 24 Nm | |
| Shear Strength Nmm² | (DIN 54452) | 8 - 13 N/mm² |
| Handling Strength | 10 - 20 min. | |
| Final Strength | (100% strength) | 3 - 6 h |
| Temperature Resistance | -60°C to +200°C | |
| Compressive Strength (free cutting steel / grub screw = 8.8) | ||
| M_3x6 | Max. 1500 bar | |
| M_4x6 | Max. 1500 bar | |
| M_5x8 | Max. 1500 bar | |
| M_6x10 | Max. 1500 bar | |
| M_8x12 | Max. 900 bar | |
| M_10x16 | Max. 400 bar | |
| LOCTITE SPESIFICATION | |
| Application | Rigid Assembly Gasketing, Sealing |
| Basic Chemical Materials | Methacrylate |
| Physical Form | Gel |
| Shear Strength Lab | 6.0 N/mm² |
| Key Characteristics | Fluorescent, Strength: Medium Strength, Thixotropic, For machine-made rigid flanges |
| Application Method | Manual, Dosing system |
| Gap Filling | 0.25mm |
| Substrate | Metal: Aluminum, Metal: Steel |
| Technology | Acrylic |
| Drying Type | Anaerobic Drying |
| Viscosity, Brookfield - HBT, @ 25.0°C Spindle TB, speed 0.5 rpm, Helipath | 700000.0 - 1700000.0 mPa.s (cP) |
| Viscosity, Brookfield - HBT, @ 25.0°C Spindle TB, speed 5.0 rpm, Helipath | 150000.0 - 375000.0 mPa.s (cP) |
| Fixture Time | 30.0 min. |
| Color | Purple |
