PFERD TC-Burrs KUD 0807/6 Steel EAN 4007220936849
With the innovative STEEL cut, PFERD has developed unique burrs for working with steel and cast steel. They feature tangibly increased aggressiveness and good guidance. They thus ensure safe and precise work. Thanks to their extremely high stock removal rate, burrs with the STEEL cut help users save considerable time when working, thus making them an economically efficient option. Ball-shaped burr according to DIN 8032.
Materials that can be worked
- Case-hardened steels
- Cast steel
- Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC)
- Steel
- Steel, cast steel
- Steels over 700 N/mm² (> 220 HB)
- Steels up to 1,200 N/mm² (< 38 HRC)
- Steels up to 700 N/mm² (< 220 HB)
- Tool steels
Applications
- Cutting out holes
- Deburring
- Leveling
- Milling
- Milling out
- Surface work
- Work on weld seams
Drive types
- Flexible shaft drive
- Robot
- Stationary machines
- Straight grinder
- Tool machine
Specification
Name
PFERD TC-Burrs KUD 0807/6 Steel EAN 4007220936849
SKU
4007220936849
Brand
Condition
New
| Cut | STEEL |
| Dia. external | 8 mm / 5/16 Inch |
| Dia. shank | 6 mm |
| Length, cut | 7 mm |
| Length, total | 47 mm / 1.27/32 Inch |
| RPM from, hardened, heat-treated steels over 1,200 N/mm² | 18000 RPM |
| RPM from, steels up to 1,200 N/mm² | 18000 RPM |
| RPM to, hardened, heat-treated steels over 1,200 N/mm² | 30000 RPM |
| RPM to, steels up to 1,200 N/mm² | 30000 RPM |
