PFERD TC Burr Cylindrical ZYA Dia. 10 x 13MM Z3P Universal Medium Cross Cut EAN 4007220045596
Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys. It is characterized by its high stock removal rate. Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing. They provide a good stock removal rate and are not specific to a particular material.
Cylindrical burr according to DIN 8032 with cut conforming to DIN 8033.
Features
Specification
| Materials that can be worked | Applications |
|
|
| Drive types | |
|
Name
PFERD TC Burr Cylindrical ZYA Dia. 10 x 13MM Z3P Universal Medium Cross Cut EAN 4007220045596
SKU
4007220045596
Brand
Condition
New
| Cut | 3 PLUS |
| Diameter (external) | 10 mm |
| Diameter (shank) | 6 mm |
| Length (cut) | 13 mm |
| Length (total) | 53 mm |
| RPM (min) for grey cast iron, white cast iron | 14,000 RPM |
| RPM (min) for hardened, heat-treated steels (over 1,200 N/mm²) | 8,000 RPM |
| RPM (min) for high-temperature-resistant materials | 8,000 RPM |
| RPM (min) for rust and acid-resistant steels | 8,000 RPM |
| RPM (min) for steels up to 1,200 N/mm² | 14,000 RPM |
| RPM (max) for grey cast iron, white cast iron | 19,000 RPM |
| RPM (max) for hardened, heat-treated steels (over 1,200 N/mm²) | 11,000 RPM |
| RPM (max) for high-temperature-resistant materials | 14,000 RPM |
| RPM (max) for rust and acid-resistant steels | 11,000 RPM |
| RPM (max) for steels up to 1,200 N/mm² | 19,000 RPM |
