Pferd Overlap Slotted Disc KS50-4 G80 EAN 4007220152768
- Reaching hard-to-reach places as grinding with the top and bottom is possible.
- High profitability through quick tool changes.
Name
Pferd Overlap Slotted Disc KS50-4 G80 EAN 4007220152768
SKU
KS50-4G80
Brand
Condition
New
| Opt. RPM of | 4000 RPM |
| Max RPM | 8000 RPM |
| diameter | 50 mm |
| width | 5 mm |
| Grain size | 80 |
| number of layers | 4 pieces |
Special tool with centric thread mount for side grinding in grooves, fillets and slots.
Machinable materials:
- aluminum
- copper
- Other non-ferrous metals
- Soft non-ferrous metal
- Brass
- Gray / ductile iron (GG / GJL, GGG / GJS)
- Malleable cast iron
- Hardened, quenched and tempered steels over 1,200 N / mm2 (over 38 HRC)
- Steel materials with a hardness over 54 HRC
- Steel, cast steel
- Steels up to 1,200 N / mm2 (<38 HRC)
- Cast steel
Processing tasks:
- Equalize
- Deburring
- Surface processing
- Weld seam processing
- Structuring (matting, matting and satin finishing)
- Gradual fine grinding
Drive types:
- Flexible shaft drive
- Straight grinder
