Sell PFERD EAN 4007220292747 Aluminium Oxide Mounted Flap Wheel F Dia. 30 x 30MM Shank Dia. 6MM A60

Add Enquiry Added

PFERD EAN 4007220292747 Aluminium Oxide Mounted Flap Wheel F Dia. 30 x 30MM Shank Dia. 6MM A60

On mounted flap wheels, the flaps made of coated abrasive are arranged radially around the tool axis in a fan-type structure. Their flexibility enables them to adapt perfectly to the contours of the workpiece. The abrasive grain is embedded in the sturdy, flexible cloth backing material by means of a resinoid bond.

In ISO 3919, mounted flap wheels are designated as "flap wheels with shaft".

For general applications from coarse to fine grinding.

Features

Specification


			Materials that can be worked
			Applications

			Aluminium
Annealed cast iron
Brass
Cast steel
Copper
Grey/nodular cast iron (GG/GJL, GGG/GJS)
Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC)
Stainless steel (INOX)
Steel materials with a hardness > 54 HRC
Steels up to 1,200 N/mm² (< 38 HRC)

			Deburring
Leveling
Step-by-step fine grinding
Structuring (matt finishing, brush matting and satin finishing)
Surface work
Work on weld seams

			Drive types

			Drive spindle
Flexible shaft drive
Straight grinder

Name

PFERD EAN 4007220292747 Aluminium Oxide Mounted Flap Wheel F Dia. 30 x 30MM Shank Dia. 6MM A60

SKU

4007220292747

Brand

PFERD

Condition

New

Abrasive	Aluminium oxide A
Diameter (external)	30 mm
Diameter (shank)	6 mm
Grit size	60
Length (shank)	40 mm
Max. RPM	25400 RPM
RPM (optimum)	12000 RPM
Width	30 mm

Materials that can be worked	Applications
Aluminium Annealed cast iron Brass Cast steel Copper Grey/nodular cast iron (GG/GJL, GGG/GJS) Hardened, heat-treated steels over 1.200 N/mm² (< 38 HRC) Stainless steel (INOX) Steel materials with a hardness > 54 HRC Steels up to 1,200 N/mm² (< 38 HRC)	Deburring Leveling Step-by-step fine grinding Structuring (matt finishing, brush matting and satin finishing) Surface work Work on weld seams
	Drive types
	Drive spindle Flexible shaft drive Straight grinder
