PFERD EAN 4007220050040 TC Burr Oval TRE Dia. 06 x 10MM Z3P Universal Medium Cross Cut
- Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys. It is characterized by its high stock removal rate.
- Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing. They provide a good stock removal rate and are not specific to a particular material.
- Oval burr according to DIN 8032 with cut conforming to DIN 8033.
Features
Specification
| Materials that can be worked | Applications |
|
|
| Drive types | |
|
Name
PFERD EAN 4007220050040 TC Burr Oval TRE Dia. 06 x 10MM Z3P Universal Medium Cross Cut
SKU
4007220050040
Brand
Condition
New
| Cut | 3 PLUS |
| Diameter (External) | 6 mm |
| Diameter (Shank) | 3 mm |
| Length (Cut) | 10 mm |
| Length (Total) | 1,575 / 40 mm |
| RPM (From) - Grey Cast Iron, White Cast Iron | 24,000 RPM |
| RPM (From) - Hardened, Heat-Treated Steels (over 1,200 N/mm²) | 13,000 RPM |
| RPM (From) - High-Temperature-Resistant Materials | 13,000 RPM |
| RPM (From) - Rust and Acid-Resistant Steels | 13,000 RPM |
| RPM (From) - Steels (up to 1,200 N/mm²) | 24,000 RPM |
| RPM (To) - Grey Cast Iron, White Cast Iron | 32,000 RPM |
| RPM (To) - Hardened, Heat-Treated Steels (over 1,200 N/mm²) | 19,000 RPM |
| RPM (To) - High-Temperature-Resistant Materials | 24,000 RPM |
| RPM (To) - Rust and Acid-Resistant Steels | 19,000 RPM |
| RPM (To) - Steels (up to 1,200 N/mm²) | 32,000 RPM |
| Radius Corner Design | 2.8 mm |
