PFERD EAN 4007220049662 TC Burr Cylindrical with radius end WRC dia. 03 x 13MM Z3P Universal Medium Cross Cut
Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys. It is characterized by its high stock removal rate.
Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing. They provide a good stock removal rate and are not specific to a particular material.
Cylindrical burr with radius end according to DIN 8032 with cut conforming to DIN 8033. Combination of cylindrical and ball-shaped geometries.
Features
Specification
| Materials that can be worked | Annealed cast iron, Black annealed cast iron (GTS, GJMB), Case-hardened steels, Cast iron, Cast steel, Cobalt-based alloys, Grey/nodular cast iron (GG/GJL, GGG/GJS), Hard aluminium alloys, Hardened, heat-treated steels over 1,200 N/mm² (< 38 HRC), High-temperature-resistant materials, Nickel-based alloys (e.g. Inconell and Hastelloy), Stainless steel (INOX), Steel, Cast steel, Steels over 700 N/mm² (> 220 HB), Steels up to 1,200 N/mm² (< 38 HRC), Steels up to 700 N/mm² (< 220 HB), Tool steels, White annealed cast iron (GTW, GJMW) |
| Applications | Cutting out holes, Deburring, Leveling, Milling, Milling out, Surface work, Work on weld seams |
| Drive Types | Drive spindle, Flexible shaft drive, Robot, Stationary machines, Straight grinder, Tool machine |
Name
PFERD EAN 4007220049662 TC Burr Cylindrical with radius end WRC dia. 03 x 13MM Z3P Universal Medium Cross Cut
SKU
4007220049662
Brand
Condition
New
| Product | Cut3 PLUS |
| Diameter (External) | 3 mm |
| Diameter (Shank) | 3 mm |
| Length (Cut) | 13 mm |
| Length (Total) | 43 mm |
| RPM from, Grey Cast Iron/White Cast Iron | 48000 RPM |
| RPM from, Hardened/Heat-treated Steels over 1,200 N/mm² | 27000 RPM |
| RPM from, High-temperature-resistant Materials | 27000 RPM |
| RPM from, Rust and Acid-resistant Steels | 27000 RPM |
| RPM from, Steels up to 1,200 N/mm² | 48000 RPM |
| RPM to, Grey Cast Iron/White Cast Iron | 64000 RPM |
| RPM to, Hardened/Heat-treated Steels over 1,200 N/mm² | 37000 RPM |
| RPM to, High-temperature-resistant Materials | 48000 RPM |
| RPM to, Rust and Acid-resistant Steels | 37000 RPM |
| RPM to, Steels up to 1,200 N/mm² | 64000 RPM |
