- Easy to operate and maintain
- Dependable design reduces downtime and repair costs
- Multiple package configurations to fit your specific application
- Reliable Monark and President air motors
- Proven and durable
| Monark and President Pumps | |
|
Metric |
|
| Model 239140 SST President | |
| Ratio |
46:1 |
| Maximum fluid working pressure |
32 MPa, 317 bar |
| Maximum air input pressure |
0.7 MPa, 7 bar |
| Fluid flow at 60 cycles per |
2.1 liters/min |
| Maximum pump operating temperature |
82°C |
| Weight |
11 kg |
| Wetted parts |
AISI 304, 316, 440C, and 17–4 PH grades of stainless steel; tungsten carbide; PTFE; leather |
| Model 223596 CST Monark | |
| Ratio |
23:1 |
| Maximum fluid working pressure |
19 MPa, 190 bar |
| Maximum air input pressure |
0.8 MPa, 8 bar |
| Fluid flow at 60 cycles per |
1.5 liters/min |
| Maximum pump operating temperature |
82°C |
| Weight |
11 kg |
| Wetted parts |
carbon steel; AISI 304, 316, 420, 440C, and 17–4 PH grades of stainless steel; chrome; chrome and zinc plating; tungsten carbide; PTFE; leather |
| Model 237958 SST Monark | |
| Ratio |
23:1 |
| Maximum fluid working pressure |
24 MPa, 238 bar |
| Maximum air input pressure |
1.0 MPa, 10 bar |
| Fluid flow at 60 cycles per |
1.5 liters/min |
| Maximum pump operating temperature |
82°C |
| Weight |
11 kg |
| Wetted parts |
AISI 304, 316, 440C, and 17–4 PH grades of stainless steel; tungsten carbide; PTFE; leather |
| Sound Pressure Levels (dBa) *measured at 1 meter from unit | |
|
Input Air Pressures at 15 cycles per minute |
|
| Air Motor |
100 psi (0.7 MPa, 7 bar) |
| President |
80.9 dB(A) |
| Monark |
63.9 dB(A) |
| Sound Power Levels (dBa) *tested in accordance with ISO 9614–2 | |
|
Input Air Pressures at 15 cycles per minute |
|
| Air Motor |
100 psi (0.7 MPa, 7 bar) |
| President |
94.6 dB(A) |
| Monark |
71.0 dB(A) |
| 30 to 1 Ratio President Sprayer | |
| Maximum working pressure |
210 bar |
| Maximum incoming air pressure |
7 bar |
| Ratio |
30:1 |
| Wetted Parts |
Pump: See 306981, Spray Gun: See 308236, Fluid Hose: Nylon, Fluid Filter: See 307273, Suction hose and Tube: Nylon, Aluminum |
